| Models: | LTI-93LT
LTI-75LT |
|
| Ladder: | All Steel construction with
k-bracing
Dual-rod extension system with Triangulated Lifting Configuration (TLC) |
|
| Modular Aerial Platform: | 1000lbs Capacity | |
| Waterway flow Rating: | LTI-100LT | |
| LTI-93LT | 1250 gpm | |
| LTI-75LT | 1000 gpm | |
| Horizontal Reach: | LTI-100LT | |
| LTI-93LT | ||
| LTI-75LT | ||
| Angle of Elevation: | -10 to 78 | |
| Outrigger Configuration: | LTI-100LT | Quantity 4, H-type out and down, 2 stabilizing jacks below front bumper |
| LTI-93LT | Quantity 4, H-type out and down, 2 stabilizing jacks below front bumper | |
| LTI-75LT | Quantity 2, H-type out and down, 2 stabilizing jacks below front bumper | |
| Outrigger Spread: | LTI-100LT | 18' mid position and 16' rear position |
| LTI-93LT | 18' mid position and 16' rear position | |
| LTI-75LT | 18' mid position, 2 stabilizing jacks below front bumper | |
| Overall Length (typ): | LTI-100LT | |
| LTI-93LT | 46' to 48' | |
| LTI-75LT | 45' to 46' | |
| Overall Height (typ): | LTI-100LT | 9'10" to 11'0" |
| LTI-93LT | 9'10" to 11'0" | |
| LTI-75LT | 9'10" to 11'0" | |
| Wheelbase Range (typ): | LTI-100LT | |
| LTI-93LT | 234" to 268" | |
| LTI-75LT | 222" to 242" | |
| Available Chassis: | American LaFrance Eagle | |
| Available Pumps: | Hale model 8FG, single stage, 1500gpm and 2000gpm | |
| Additional Available Optional Features: | ||
